DtcGridBundle

Generate a searchable Grid from a Doctrine ORM Entity or Doctrine MongoDB Document

Utilize jQuery DataTables, jqGrid(*), or a Styled HTML Table(*) Easily styled using Bootstrap Customize columns and more... (new as of 2.0): Easy to install, easy get started

(*) search functionality supported on DataTables only

Render customizable tables using jqGrid, or jQuery DataTables, or in a Styled HTML Table.

Supports both Doctrine ORM and Doctrine MongoDB ODM

Installation

Symfony 4/5

composer.phar require mmucklo/grid-bundle

You may see something like this (please answer 'y' to the question if prompted):

- WARNING mmucklo/grid-bundle (>=5.0): From github.com/symfony/recipes-contrib:master The recipe for this package comes from the "contrib" repository, which is open to community contributions. Review the recipe at https://github.com/symfony/recipes-contrib/tree/master/mmucklo/grid-bundle/4.0 Do you want to execute this recipe? [y] Yes [n] No [a] Yes for all packages, only for the current installation session [p] Yes permanently, never ask again for this project (defaults to n): y - Configuring mmucklo/grid-bundle (>=5.0): From github.com/symfony/recipes-contrib:master

Symfony 2/3

Add this to your AppKernel.php file:

public function registerBundles() { $bundles = [ ... new DtcGridBundleDtcGridBundle(), ... ]

Add this to your app/config/routing.yml file:

dtc_grid: resource: '@DtcGridBundle/Resources/config/routing.yml'

Usage

Get Started

After installation, all entities and documents that have a Grid annotation should be available off the dtc_grid route:

(NOTE: symfony5 example below, for symfony2/3, the namespace for the class may be different - e.g. AppBundle instead of App)

There are two recommended ways to setup a grid for a page, through Annotations, or through Reflection

Reflection

Automatic Grid setup is possible by setting the reflections: allowed_entities: [...] parameter in the config/packages/dtc_grid.yaml configuration file (or config.yml for symfony <= 3.4)

dtc_grid: reflection: # allow any entity to be shown via the /dtc_grid route # allowed_entities: ~, '*', or an array of entity names [ 'App:Product', 'App:Category', ... ] # ~ - no entities allowed for reflection # * - all entities allowed for reflection # [ 'App:Product', 'App:Category' ] - only App:Product and App:Category allowed allowed_entities: ~

(New in 6.0) grid yaml file definition

You can place the grid column definitions in a custom yaml file:

Step 1 - create the yaml file:

# File location(s): # - symfony 4+: config/dtc_grid/*.yaml (will load all *.yaml files in this directory) # - symfony 2/3: src/*/*/Resources/config/dtc_grid.yaml (will only load files with this name or the name 'dtc_grid.yml') # - custom (bundles): add the following to a CompilerPass: # # $cacheDir = $container->getParameter('kernel.cache_dir'); # DtcGridBundleGridSourceColumnSource::cacheClassesFromFile($cacheDir, $filename); AppUser: columns: id: sortable: true username: sortable: true searchable: true email: searchable: true createdAt: sortable: true updatedAt: sortable: true status: sortable: true searchable: true actions: - label: Show type: show route: dtc_grid_show - label: Archive type: delete route: dtc_grid_delete sort: id: ASC AppArticle: columns: id: sortable: true userId: sortable: true createdAt: sortable: true updatedAt: sortable: true subject: searchable: true status: sortable: true actions: - label: Show type: show route: dtc_grid_show - label: Custom onclick: "alert('custom action')" button_class: btn-info sort: createdAt: DESC

Annotation Simple Example

Note: this example still uses reflection to discover the columns, however if you want to customize the columns shown, and even which ones are shown, read on below in the section titled Customize Columns

<?php namespace AppEntity; use DoctrineORMMapping as ORM; use DtcGridBundleAnnotation as Grid; /** * Class User * @GridGrid * @ORMEntity * @package AppEntity */ class User { //... }

Now after adding the annotation, you may need to do:

bin/console cache:clear bin/console cache:warmup

To access the grid:

You can access the grid without embedding it anywhere by going to the following url(s):

Route: dtc_grid/dtc_grid/grid?class=App:User Parameters: class=[document_or_entity] This can be in either a fully-namespaced class name or symfony-style entity/document format separated by ':' e.g. either: 'App:User' or 'AppEntityUser' type=[datatables|table|jq_grid]

Examples:

# A default HTML-based table # (warning: if your table is large, skip this example, and try the paginated datatables path below) # Datatables /dtc_grid/grid?class=App:User&type=datatables # Full Class syntax /dtc_grid/grid?class=AppEntityUser&type=datatables # MongoDB ODM examples /dtc_grid/grid?class=App:Event&type=datatables /dtc_grid/grid?class=AppDocumentEvent&type=datatables # Other types of tables /dtc_grid/grid?class=App:Event&type=jq_grid /dtc_grid/grid?class=App:Event&type=table

Note - Security

For production systems you may want to add the path ^/dtc_grid to your security.yml, and make it firewalled / admin-only:

security: # ... access_control: # ... - { path: ^/dtc_grid, roles: ROLE_ADMIN }

Adding actions

There are presently several actions that you can add to your grid that will appear under a final column called "Actions"

These must be added as annotations to the Grid annotation.

<?php namespace AppEntity; use DoctrineORMMapping as ORM; use DtcGridBundleAnnotation as Grid; /** * Class User * @GridGrid(actions={@GridShowAction(), @GridDeleteAction(), @GridAction(label="Custom",buttonClass="btn-info",onclick="alert('custom-action')")}) * @ORMEntity * @package AppEntity */ class User { //... }

A more custom Route

/** * @Route("/users", name="app_grid_users") */ public function usersAction(Request $request) { $renderer = $this->get('dtc_grid.renderer.factory')->create('datatables'); $gridSource = $this->get('dtc_grid.manager.source')->get('App:User'); $renderer->bind($gridSource); return $this->render('@DtcGrid/Page/datatables.html.twig', $renderer->getParams()); }

Changing the renderer

/** * @Route("/users_table", name="app_grid_users_table") */ public function usersAction(Request $request) { $renderer = $this->get('dtc_grid.renderer.factory')->create('table'); $gridSource = $this->get('dtc_grid.manager.source')->get('App:User'); $renderer->bind($gridSource); return $this->render('@DtcGrid/Page/datatables.html.twig', $renderer->getParams()); }

Customize Columns

There's a @Column annotation that lives in DtcGridBundleAnnotation that you place on each column you want to be visible. Then you can specify a custom label, and or sortability if you want. If there's no @GridColumn annotations at all, it will default to show all the columns.

<?php namespace AppEntity; use DoctrineORMMapping as ORM; use DtcGridBundleAnnotation as Grid; /** * Class User * @GridGrid * @ORMEntity * @package AppEntity */ class User { /** * @ORMColumn(type="integer") * @ORMId * @ORMGeneratedValue(strategy="AUTO") */ protected $id; /** * @GridColumn(searchable=true) * @ORMColumn(type="string") */ protected $firstName; /** * @GridColumn(label="Last", sortable=true, searchable=true) * @ORMColumn(type="string") */ protected $lastName;

Customize jQuery, Purl, DataTables

Customization of the versions of jQuery, Purl, and DataTables can be done in config.yml

dtc_grid: theme: # theme defaults to bootstrap 3 css: - 'path_or_url_to/bootstrap_or_any_other.css' - 'etc. as necessary' js: - 'path_or_url_to/any_javascript_needed_for_theme.js' - 'etc. as necessary' purl: 'path_or_url_to/purl.js' # presently defaults to v2.3.1 hosted on cdnjs jquery: # presently defaults to 3.2.1 hosted on jquery's code.jquery.com cdn url: 'path_or_url_to/jquery.js' integrity: ~ # or an integrity for the file crossorigin: ~ # or what goes in the crossorigin section of the script tag datatables: # presently defaults to 1.10.16 hosted on cdn.datatables.net css: - 'path_or_url_to/datatables.css' - 'path_or_url_to/any_other_needed.css' js: - 'path_or_url_to/datatables.js' - 'path_or_url_to/datatables_theme.js' - 'etc. as necessary'

JQ Grid

To use JQ Grid, you need to specify the absolute URL, or relative/absolute path to the JQGrid files.

As JQ Grid has a different license than this bundle, there are no defaults provided.

# config.yml dtc_grid: jq_grid: css: - 'path_or_url_to/prettify.css' - 'path_or_url_to/ui.jqgrid-bootstrap.css' js: - 'path_or_url_to/grid.locale-en.js' - 'path_or_url_to/jquery.jqGrid.js'

/** * @Route("/users_table", name="app_grid_users_table") */ public function usersAction(Request $request) { $renderer = $this->get('dtc_grid.renderer.factory')->create('jq_grid'); $gridSource = $this->get('dtc_grid.manager.source')->get('App:User'); $renderer->bind($gridSource); return $this->render('@DtcGrid/Page/datatables.html.twig', $renderer->getParams()); }

Customize Bootstrap

# config.yml dtc_grid: bootstrap: css: path_or_url_to_bootstrap.css js: path_or_url_to_bootstrap.js

Multiple Grids on the same page

The RendererFactory needs to be used if you want to render multiple grids on the same page.

There are presently three typs of renderers it supports:

datatables jq_grid table

/** * List jobs in system by default. * * @Route("/jobs/") */ public function jobsAction() { $rendererFactory = $this->get('dtc_grid.renderer.factory'); $renderer = $rendererFactory->create('datatables'); $gridSource = $this->get('dtc_grid.manager.source')->get('DtcQueueBundleDocumentsJob'); $renderer->bind($gridSource); $params = $renderer->getParams(); $renderer2 = $rendererFactory->create('datatables'); $gridSource2 = $this->get('dtc_grid.manager.source')->get('DtcQueueBundleDocumentsJobArchive'); $renderer2->bind($gridSource2); $params2 = $renderer2->getParams(); $params['archive_grid'] = $params2['dtc_grid']; return $this->render('@DtcQueue/Queue/jobs.html.twig', $params); }

Twig file rendering the multiple grids on the same page

jobs.html.twig:

{% extends "DtcGridBundle:Page:datatables.html.twig" %} {% block grid %} <h3>Live Jobs</h3> {{ dtc_grid.render | raw }} <h3>Archived Jobs</h3> {{ archive_grid.render | raw }} {% endblock %}

You can even render multiple types of grids on the same page

/** * List jobs in system by default. * * @Route("/jobs/") */ public function jobsAction() { $rendererFactory = $this->get('dtc_grid.renderer.factory'); $renderer = $rendererFactory->create('jq_grid'); // NOTE THE DIFFERENT GRID TYPE $gridSource = $this->get('dtc_grid.manager.source')->get('DtcQueueBundleDocumentsJob'); $renderer->bind($gridSource); $params = $renderer->getParams(); $renderer2 = $rendererFactory->create('datatables'); $gridSource2 = $this->get('dtc_grid.manager.source')->get('DtcQueueBundleDocumentsJobArchive'); $renderer2->bind($gridSource2); $params2 = $renderer2->getParams(); $params['archive_grid'] = $params2['dtc_grid']; return $this->render('@DtcQueue/Queue/jobs.html.twig', $params); }

jobs.html.twig (a little complicated as styles and javascript has to be included for both grid types, although this isn't necessary if you use the "table" type renderer as it's CSS and Javascript overlaps with the "datatables" renderer):

{% extends '@DtcGrid/layout_base_jquery.html.twig' %} {% block dtc_grid_stylesheets %} {% for stylesheet in dtc_grid_jq_grid_css %} <link rel="stylesheet" href="{{ stylesheet }}" /> {% endfor %} {% for stylesheet in dtc_grid_datatables_css %} <link rel="stylesheet" href="{{ stylesheet }}" /> {% endfor %} {% endblock %} {% block dtc_grid_javascripts %} {{ parent() }} {% for javascript in dtc_grid_jq_grid_js %} <script type="text/javascript" src="{{ javascript }}"></script> {% endfor %} {% for javascript in dtc_grid_datatables_js %} <script src="{{ javascript }}"></script> {% endfor %} {% endblock %} {% block grid %} <h3>Live Jobs</h3> {{ dtc_grid.render | raw }} <h3>Archived Jobs</h3> {{ archive_grid.render | raw }} {% endblock %}

Customize/Embed Grid

To customize the grid's CSS/Javascript, or embed it into an existing page, follow the example below:

/** * @Route("/users_custom", name="app_grid_users_custom") */ public function usersCustomAction(Request $request) { // other setup, etc. // Assuming you have a variable called "$params" $renderer = $this->get('dtc_grid.renderer.factory')->create('datatables'); // or whichever renderer you want to use $gridSource = $this->get('dtc_grid.manager.source')->get('App:User'); $renderer->bind($gridSource); $renderer->getParams($params); // This will add the grid-specific params (mainly 'grid', and the bootstrap urls) // Alternatively you can do // $dataGridParams = $renderer->getParams(); // $myParams['my_grid'] = $dataGridParams['dtc_grid']; // render your page return $this->render('@App/Something/somepage.html.twig', $params); }

Datatables Twig Example:

<html> <head> {% block stylesheets %} {% for stylesheet in dtc_grid_theme_css %} <link rel="stylesheet" href="{{ stylesheet }}"> {% endfor %} {% endblock %} {% block dtc_grid_stylesheets %} {% for stylesheet in dtc_grid_datatables_css %} <link rel="stylesheet" href="{{ stylesheet }}" /> {% endfor %} {% for stylesheet in dtc_grid_local_css %} <link rel="stylesheet" href="{{ app.request.baseUrl }}{{ stylesheet }}" /> {% endfor %} {% endblock %} {% block dtc_grid_javascripts %} <script src="{{ dtc_grid_jquery.url }}" {% if dtc_grid_jquery.integrity is not empty %} integrity="{{ dtc_grid_jquery.integrity }}"{% endif %} {% if dtc_grid_jquery.crossorigin is not empty %} crossorigin="{{ dtc_grid_jquery.crossorigin }}"{% endif %}> </script> <script src="{{ dtc_grid_purl }}"></script> {% for javascript in dtc_grid_datatables_js %} <script src="{{ javascript }}"></script> {% endfor %} {% endblock %} {% block javascripts %} {% for javascript in dtc_grid_theme_js %} <script src="{{ javascript }}"></script> {% endfor %} {% for javascript in dtc_grid_local_js %} <script src="{{ app.request.baseUrl }}{{ javascript }}"></script> {% endfor %} {% endblock javascripts %} </head> <body> <!-- .... --> {# This is the most important part - 'dtc_grid.render' should be 'dtc_grid.render' or 'my_grid.render', or whatever you called it if you change the parameter's name #} {{ dtc_grid.render | raw }} <!-- ... --> </body> </html>

JQGrid Twig Example:

<html> <head> {% block stylesheets %} {% for stylesheet in dtc_grid_theme_css %} <link rel="stylesheet" href="{{ stylesheet }}"> {% endfor %} {% for stylesheet in dtc_grid_local_css %} <link rel="stylesheet" href="{{ app.request.baseUrl }}{{ stylesheet }}" /> {% endfor %} {% endblock %} {% block dtc_grid_stylesheets %} {% for stylesheet in dtc_grid_jq_grid_css %} <link rel="stylesheet" href="{{ stylesheet }}" /> {% endfor %} {% endblock %} {% block dtc_grid_javascripts %} <script src="{{ dtc_grid_jquery.url }}" {% if dtc_grid_jquery.integrity is not empty %} integrity="{{ dtc_grid_jquery.integrity }}"{% endif %} {% if dtc_grid_jquery.crossorigin is not empty %} crossorigin="{{ dtc_grid_jquery.crossorigin }}"{% endif %}> </script> <script src="{{ dtc_grid_purl }}"></script> {% for javascript in dtc_grid_jq_grid_js %} <script type="text/javascript" src="{{ javascript }}"></script> {% endfor %} {% endblock %} {% block javascripts %} {% for javascript in dtc_grid_theme_js %} <script src="{{ javascript }}"></script> {% endfor %} {% for javascript in dtc_grid_local_js %} <script src="{{ app.request.baseUrl }}{{ javascript }}"></script> {% endfor %} {% endblock javascripts %} </head> <body> <!-- .... --> {# This is the most important part - 'dtc_grid.render' should be 'dtc_grid.render' or 'my_grid.render', or whatever you called it if you change the parameter's name #} {{ dtc_grid.render | raw }} <!-- ... --> </body> </html>

Table Twig Example:

<html> <head> {% block stylesheets %} {% for stylesheet in dtc_grid_theme_css %} <link rel="stylesheet" href="{{ stylesheet }}"> {% endfor %} {% for stylesheet in dtc_grid_local_css %} <link rel="stylesheet" href="{{ app.request.baseUrl }}{{ stylesheet }}" /> {% endfor %} {% endblock %} {% block javascripts %} {% for javascript in dtc_grid_theme_js %} <script src="{{ javascript }}"></script> {% endfor %} {% for javascript in dtc_grid_local_js %} <script src="{{ app.request.baseUrl }}{{ javascript }}"></script> {% endfor %} {% endblock javascripts %} </head> <body> <!-- .... --> {# This is the most important part - 'dtc_grid.render' should be 'dtc_grid.render' or 'my_grid.render', or whatever you called it if you change the parameter's name #} {{ dtc_grid.render | raw }} <!-- ... --> </body> </html>

Documentation

There is additional (somewhat legacy at this point) documentation stored in Resources/doc/

Legacy:

You used to have to use a "Generator" to create the grid.source service, however this is no longer necessary, however documentation on how to use it is still available in the Resources/doc/ area.

License

This bundle is under the MIT license (see LICENSE file under Resources/meta/LICENSE).

Credit

Originally written by @dtee Maintained by @mmucklo
